Nova GPU Driver

Nova is a driver for GSP (GPU system processor) based Nvidia GPUs. It is intended to become the successor of Nouveau as the mainline driver for Nvidia (GSP) GPUs in Linux.

It will support all Nvidia GPUs beginning with the GeForce RTX20 (Turing family) series and newer.

Contact

Available communication channels are:

  • The mailing list: nouveau@lists.freedesktop.org
  • IRC: #nouveau on OFTC
  • Zulip Chat

Resources

The parts that are already in mainline Linux can be found in drivers/gpu/nova-core/ and drivers/gpu/drm/nova/

The development repository for the in-tree driver is located on Freedesktop.

Background

Why a new driver?

Nouveau was, for the most part, designed for pre-GSP hardware. The driver exists since ~2009 and its authors back in the day had to reverse engineer a lot about the hardware's internals, resulting in a relatively difficult to maintain codebase.

Moreover, Nouveau's maintainers concluded that a new driver, exclusively for GSP hardware, would allow for significantly simplifying the driver design: Most of the hardware internals that Nouveau had to reverse engineer reside in the GSP firmware. Hereby, the GSP takes up the role of a hardware abstraction layer which communicates with the host kernel through IPC. Thereby, a lot of the stack's complexity is moved from the GPU driver into the GSP firmware.

This, in consequence, enables better maintainability. Another chance with a new driver is to obtain active community participation from the very beginning.

Why write it in Rust?

Besides Rust's built-in ownership and lifetime model, its powerful type system allows us to avoid a large portion of a whole class of bugs (i.e. memory safety bugs).

Additionally, the same features allow us to model APIs in a way that also certain logic errors can be caught at compile time already.

Especially GPU drivers can benefit a lot from Rust's ownership and lifetime model, given their highly concurrent and asynchronous design.

Since Nova is a new driver, written from scratch, it is an opportunity to try to leverage the advantages of Rust and obtain a more reliable, maintainable driver.

Architecture

Nova Architecture with vGPUs

The overall GPU driver is split into two parts:

  1. "Nova-Core", living in drivers/gpu/nova-core/. Nova-Core implements the fundamental interaction with the hardware (through PCI etc.) and, notably, boots up the GSP and interacts with it through a command queue.
  2. "Nova-DRM" (the official name is actually just "Nova", but to avoid confusion developers usually call it "Nova-DRM"), living in drivers/gpu/drm/nova/. This is the actual graphics driver, implementing all the typical DRM interfaces for userspace.

This split architecture allows for different drivers building on top of the abstraction layer provided by Nova-Core. Besides Nova-DRM, for instance, a VFIO driver to virtualize the GPU can be built on top of Nova-Core. Through this driver Nova-Core can be used to instruct the GPU's firmware to spawn new PCI virtual functions (through SR-IOV), representing virtual GPUs. Those virtual functions (or vGPUs) can be used by virtual machines. Such a virtual machine running Linux may run Nova-Core and Nova-DRM as conventional GPU drivers on top of this vGPU.

A main advantage of this design is that the amount of software running on the host (where crashes would be far more fatal than inside of a VM) is kept small, which contributes to stability.

It is also possible to use Nova-Core + Nova-DRM on one physical machine (not depicted in the diagram) in order to expose a DRM compatible uAPI to the host userspace.

For more details about vGPUs, take a look at Zhi's announcement email.

Status and Contributing

The necessary Rust infrastructure has been progressing a lot. Current work now focuses more on the actual driver. In case you want to contribute, take a look at the NOVA TODO List.

Don't hesitate reaching out on the aforementioned community channels.
